New production line in the Iron Foundry

In 2012 Metalodlew SA commissioned a new production line for high-quality iron castings with enhanced quality parameters.

Stand for technology design System MAGMASOFT®
Stand for technology design System MAGMASOFT®
  • Shorter time for product implementation

  • Possibility to choose the optimal casting technology regarding costs and funcional properties.



Induction melting shop
Induction furnace double crucible of medium frequency OTTO JUNKER

Induction furnace double crucible of medium frequency
OTTO JUNKER

  • Crucible volume: 2 x 12 tons
  • Melting efficiency: 11,7 tons per hour
  • Temperature of melting iron: to 1520°C
  • Possibility to melt iron in one crucible and in the same time keeping the temperature of melted iron in the second crucible.
  • Cloced non-glicolic water cooling system of the furnace, „water-air” type using cooler ventilators
Knocking-out stand and the regeneration of the used molds,
vibrating grate (FMO), mechanical regeneration (IMF)
Knocking-out stand and the regeneration of the used  molds, vibrating grate (FMO), mechanical regeneration (IMF)
  • vibrating grate dimension: 5 x 5 m

  • maximal load capacity: up to 50 tons

  • regeneration efficiency: 15-20 tons/hour

  • maximal recycle of 95% quartz sand from used forms.

  • closed water cooling system of the regenerator „water-air” type using cooler ventilator and the cooling unit
Stand for casting fettling
Rotary fettler STEM with rotating table
Rotary fettler STEM with rotating table
  • Maximal capacity: 30 tons

  • Very precise surface fettling of the castings with diameter to 4250 mm and heigth to 2500 mm

  • Pneumatic hand afterfettling for the hard reachable areas using buillt-up system inside fettling cabin.
Machining center
CNC machine (TOS)
CNC machine (TOS)
  • Final machining of the castings up to 30 tons and maximal dimension of 6 m

  • Posiibility of machining without using oil cooling emulsions
